In this post guide, we’ll explore the typical battery sizes used in garden tractor lawn mowers, what the battery group codes mean, how to choose the right one, and provide a comprehensive Garden Tractor Lawn Mower Battery Size Chart to help you make the best decision.
Garden Tractor Lawn Mower Battery Size Chart
| Brand/Model | Battery Group | Voltage | CCA Range | Terminal Position |
|---|---|---|---|---|
| John Deere D110 | U1R | 12V | 300–350 | Right |
| John Deere X300 | U1R | 12V | 340–370 | Right |
| John Deere X500 | 51 | 12V | 450–500 | Top |
| John Deere S240 | U1 | 12V | 300–340 | Left |
| John Deere E100 | U1 | 12V | 280–320 | Left |
| Cub Cadet XT1 Enduro Series | U1 | 12V | 300–330 | Left |
| Cub Cadet XT2 LX46 | U1R | 12V | 320–350 | Right |
| Cub Cadet ZT1 50 | U1R | 12V | 340–360 | Right |
| Husqvarna YTH24V48 | U1R | 12V | 330–350 | Right |
| Husqvarna TS 354XD | U1 | 12V | 340–360 | Left |
| Husqvarna YTA22V46 | U1 | 12V | 300–330 | Left |
| Craftsman T210 | U1R | 12V | 320–340 | Right |
| Craftsman T110 | U1 | 12V | 280–320 | Left |
| Craftsman CMXGRAM1130036 | U1 | 12V | 300–330 | Left |
| Troy-Bilt Super Bronco XP | U1 | 12V | 300–320 | Left |
| Troy-Bilt Pony 42 | U1 | 12V | 280–310 | Left |
| Troy-Bilt TB30R | U1 | 12V | 280–310 | Left |
| Toro TimeCutter SS5000 | U1R | 12V | 340–360 | Right |
| Toro TimeCutter MX5075 | U1R | 12V | 350–375 | Right |
| Toro Titan ZX4800 | U1R | 12V | 350–375 | Right |
| Snapper SPX Series | U1R | 12V | 330–350 | Right |
| Snapper 2691526 | U1 | 12V | 300–330 | Left |
| Snapper Ninja Series | U1R | 12V | 320–350 | Right |
| Ariens Ikon XD 52 | U1R | 12V | 350–375 | Right |
| Ariens Edge 44 | U1 | 12V | 300–330 | Left |
| Ariens Apex 48 | U1R | 12V | 340–360 | Right |
| Simplicity Broadmoor 23/44 | U1R | 12V | 330–360 | Right |
| Simplicity Regent 25/48 | U1R | 12V | 340–370 | Right |
| Simplicity Courier 23/42 | U1 | 12V | 320–350 | Left |
| Murray Select 42″ | U1 | 12V | 280–310 | Left |
| MTD Yard Machine 38″ | U1 | 12V | 280–310 | Left |
| MTD Gold 42″ | U1 | 12V | 300–330 | Left |
| Poulan Pro PP19A42 | U1 | 12V | 280–320 | Left |
| Poulan Pro PPX46Z | U1R | 12V | 320–350 | Right |
| Ryobi RY48140 | U1R | 12V | 300–330 | Right |
| Ryobi RY401140 | U1 | 12V | 280–310 | Left |
Related EGO Battery Comparison Chart(For All Battery Models)
Understanding Battery Group Sizes
Lawn and garden tractor batteries generally fall under the BCI (Battery Council International) Group U1, but there are variations:
- U1: Common size for most garden tractors.
- U1L: Same as U1 but with reversed terminal positions.
- U1R: Standard U1 with terminals on the right.
- Group 26, 35, or 51: Rare in garden tractors but used in some heavy-duty or hybrid units.
Related Will a Lawn Mower run with a Dead Battery(What To do)
What to Look for in a Garden Tractor Battery
When selecting a battery, consider these key factors:
- Voltage: Most garden tractors use 12-volt batteries.
- Cold Cranking Amps (CCA): Indicates the battery’s ability to start in cold weather. A higher CCA is ideal for cold climates.
- Reserve Capacity (RC): This tells how long the battery can run your mower if the alternator fails.
- Dimensions: Must fit snugly in the battery compartment.
- Terminal Orientation: U1L vs U1R affects cable reach.
Related Rural King Battery Size Chart(Ultimate Size Guide For All Applications)
Tips for Choosing the Right Lawn Tractor Battery
- Consult the Manual: Always start by checking your owner’s manual. It will tell you the recommended group size, voltage, and CCA rating.
- Measure Your Battery Compartment: If you’ve lost the original battery, measure the compartment to ensure a proper fit.
- Check the Terminals: Incorrect terminal orientation can make installation difficult or cause short circuits.
- Avoid Underpowered Batteries: Low CCA may work on warm days but fail in colder conditions.
- Maintenance-Free vs Wet Cell: Modern batteries are usually sealed and maintenance-free. Wet cell batteries need periodic electrolyte checks and top-ups.
- Look for Warranties: A good battery should come with at least a 12-month warranty for peace of mind.
Related Lawn Mower Battery Size Chart(For All Brands + Models)
Signs You Need a New Battery
- Slow Crank or No Start: If your tractor struggles to start or doesn’t crank at all, the battery may be weak.
- Corrosion around terminals indicates battery acid leakage, which can damage the terminals.
- Swollen Case or Cracks: These are physical signs of battery failure and can be dangerous.
- Old Age: Most lawn tractor batteries last 3–5 years. If it’s older, replacement is a smart move.
FAQs
Are garden tractor batteries 6 or 12 volt?
Most modern garden tractor batteries are 12-volt.
Historically, older lawn tractors (especially those made before the 1980s) used 6-volt batteries, but virtually all current models, whether John Deere, Cub Cadet, or Husqvarna, use 12-volt systems. You can confirm this by checking the battery label or the owner’s manual.
Related Greenworks Battery Compatibility Chart(For All Models)
What is the difference between U1 and U1R lawn tractor battery?
The main difference is the terminal position:
| Type | Terminal Position | Common Use |
|---|---|---|
| U1 | Left-hand (+) | Some brands/models |
| U1R | Right-hand (+) | Most common type |
- U1R (Right): Positive terminal on the right when the terminals face you.
- U1 (Left): Positive terminal on the left.
It’s crucial to match this with your mower’s cable setup. Installing the wrong one may result in cables not reaching or reversing polarity, which could damage the system.
How many amps should a riding lawn mower battery have?
A typical garden tractor battery has:
- Cold Cranking Amps (CCA): 250–400 CCA
- This is the amount of current the battery can deliver at 0°F to start the engine. The higher the CCA, the better for cold-weather starts.
- Amp-Hour (Ah): 15–35 Ah
- This indicates the amount of energy the battery can deliver over time. Riding mower batteries don’t need high Ah unless they power many accessories.
Do all lawn tractors use the same battery?
No, not all lawn tractors use the same battery, although most use a Group U1 or U1R 12V battery. However, differences may include:
- Terminal orientation (U1 vs U1R)
- CCA requirements
- Battery dimensions
- Heavy-duty or commercial models may require a larger group size (like Group 24 or higher).
What is the difference between U1 and Group 24 batteries?
| Feature | U1 Battery | Group 24 Battery |
|---|---|---|
| Voltage | 12V | 12V |
| Common Use | Lawn & garden tractors | Cars, trucks, heavy-duty |
| Size (approx.) | Smaller (7.75” L x 5” W) | Larger (10.25” L x 6.8125” W) |
| CCA | 250–400 CCA | 500–800+ CCA |
| Weight | 15–20 lbs | 35–50 lbs |
- U1 is compact and designed for low-to-moderate power needs.
- Group 24 is a much larger automotive battery, generally too big for standard riding mowers unless modified.
