Testing the starter on a riding lawn mower is a straightforward process that can save you time and money by identifying whether the starter motor is the root of the problem. In this guide, we’ll walk you through the steps to test a starter on a riding lawn mower, ensuring you have the knowledge to troubleshoot effectively.
How to Test a Starter on a Riding Lawn Mower
Tools and Materials Needed:
Before starting, gather the following tools and materials:
- Multimeter (for testing voltage and continuity)
- Wrench set or socket set
- Screwdrivers (Phillips and flathead)
- Safety gloves and glasses
- Battery charger (optional, for ensuring battery charge)
- Jumper cables (optional, for direct testing)
- Owner’s manual for your riding lawn mower
Step 1: Safety First
Safety is critical when working on any machinery. Start by parking the mower on a flat surface and engaging the parking brake. Disconnect the spark plug wire to prevent accidental starts. Remove the key from the ignition and ensure the mower is completely powered down. Wear safety gloves and glasses to protect yourself from electrical hazards or moving parts.
Step 2: Check the Battery
A weak or dead battery can mimic starter problems, so begin by testing the battery. Use a multimeter set to DC voltage to check the battery’s charge. A fully charged 12-volt battery should read between 12.6 and 12.8 volts.
If the voltage is lower than 12.4 volts, charge the battery fully and retest. Inspect the battery terminals for corrosion or loose connections. Clean any corrosion with a wire brush and tighten the connections with a wrench.
If the battery is charged and connections are secure, but the mower still won’t start, proceed to test the starter.
Related How to Tell If Your Lawn Mower Starter Is Bad(5 Signs)
Step 3: Inspect the Starter Solenoid
The starter solenoid acts as a relay between the battery and the starter motor. It’s often located near the battery or starter and has heavy cables connected to it. To test the solenoid:
- Set your multimeter to continuity mode.
- Touch the multimeter probes to the solenoid’s two large terminals. You should hear a click and see continuity (a reading close to zero ohms) when the ignition is turned to the “start” position.
- If there’s no continuity or clicking sound, the solenoid may be faulty and need replacement.
A defective solenoid can prevent power from reaching the starter, so rule this out before moving to the starter motor itself.
Step 4: Test the Starter Motor
To directly test the starter motor, you’ll need to access it. The starter is typically located near the engine, often bolted to the engine block or transmission. Refer to your owner’s manual for its exact location.
Visual Inspection
Start with a visual check. Look for signs of damage, such as burnt wires, loose bolts, or corrosion. Tighten any loose connections and clean corrosion if present.
Voltage Test
- Set your multimeter to DC voltage.
- Connect the positive (red) probe to the positive terminal on the starter (where the battery cable connects) and the negative (black) probe to a clean, unpainted metal surface on the mower’s frame (ground).
- Have a helper turn the ignition to the “start” position while you observe the multimeter.
- A reading of 12 volts or higher indicates the starter is receiving power. If there’s no voltage, recheck the wiring and solenoid.
Bench Testing the Starter
If the starter receives power but doesn’t engage, you may need to remove it for a bench test:
- Disconnect the battery to avoid electrical hazards.
- Use a wrench or socket to unbolt the starter from the mower.
- Connect jumper cables to the starter: attach the positive cable to the starter’s positive terminal and the negative cable to the starter’s body or a ground point.
- Briefly connect the other ends of the cables to a charged battery. The starter should spin or engage if it’s functioning. If it doesn’t, the starter is likely defective.
Related Lawn Mower Makes Grinding Noise When Trying to Start(Solved)
Step 5: Check Related Components
If the starter passes the tests but the mower still won’t start, other components may be at fault. Inspect the ignition switch, safety interlocks (such as the seat switch or brake switch), and wiring harness for damage or loose connections. Use the multimeter to test for continuity in these circuits, following your mower’s wiring diagram.
Step 6: Reassemble and Test
If the starter is functional and all connections are secure, reassemble any removed components. Reconnect the battery and spark plug wire. Attempt to start the mower. If it still doesn’t start, consider consulting a professional or testing the engine itself for issues like low compression or fuel problems.
Related EGO Battery Comparison Chart(For All Battery Models)
When to Replace the Starter
If the starter fails the voltage or bench test, it’s time to replace it. Purchase a compatible starter for your mower model, following the manufacturer’s specifications. Installation typically involves reversing the removal process, ensuring all connections are tight and secure.
Tips for Maintenance
To prolong the life of your starter:
- Keep the battery charged and terminals clean.
- Avoid repeated short start attempts, which can overheat the starter.
- Store the mower in a dry, sheltered area to prevent corrosion.
Related Lawn Mower Dies When Blades Engaged(8 Causes + Solutions)
FAQs
How do I know if my starter is bad on my riding lawn mower?
You may suspect a bad starter if your riding lawn mower doesn’t start, makes a clicking sound, or cranks slowly when you turn the key. Other signs include no response at all when attempting to start, even with a charged battery, or a grinding noise during startup. To confirm, test the battery, solenoid, and starter motor with a multimeter to rule out other issues.
Is there a way to test a starter to see if it’s bad?
Yes, you can test the starter by checking if it receives power and whether it engages properly. Start by using a multimeter to verify the starter is getting 12 volts when the ignition is turned to the “start” position. If it receives power but doesn’t work, remove the starter and bench-test it by connecting it to a battery with jumper cables. If it doesn’t spin, the starter is likely faulty.
Related How to Fix the Self Propel on a Toro Lawn Mower(Fixed)
How to test a riding mower starter with a multimeter?
To test the starter with a multimeter:
- Set the multimeter to DC voltage.
- Connect the red probe to the starter’s positive terminal (where the battery cable connects) and the black probe to a clean metal part of the mower’s frame (ground).
- Have someone turn the ignition to the “start” position.
- A reading of 12 volts or higher means the starter is receiving power. If there’s no voltage, check the solenoid or wiring. If power is present but the starter doesn’t engage, it may be defective.
How to diagnose a riding lawn mower that won’t start?
Diagnosing a non-starting mower involves checking multiple components:
- Battery: Ensure it’s fully charged (12.6–12.8 volts) and terminals are clean.
- Solenoid: Test for continuity across its large terminals when the ignition is in the “start” position.
- Starter: Verify it receives power and spins during a bench test.
- Other components: Inspect the ignition switch, safety interlocks (seat or brake switches), and wiring for damage or loose connections. Consult your mower’s manual for specific wiring diagrams.
How do I know for sure if my starter is bad?
To confirm a bad starter, first ensure the battery is charged and the solenoid is functioning. Then, test the starter with a multimeter to check if it’s receiving 12 volts. If it is, remove the starter and perform a bench test by connecting it directly to a battery with jumper cables. If the starter doesn’t spin or engage, it’s likely bad and needs replacement.
Why is my lawn mower not turning over but the battery is good?
If the battery is charged (12.6–12.8 volts) but the mower won’t turn over, the issue could be:
- Faulty starter: Test the starter motor to see if it’s receiving power and functioning.
- Bad solenoid: Check for continuity across the solenoid’s terminals.
- Wiring issues: Inspect for loose or corroded connections.
- Safety switches: Ensure the seat, brake, or blade engagement switches aren’t preventing startup.
- Ignition switch: Test for continuity to confirm it’s sending power to the starter circuit.
Final words
Testing a starter on a riding lawn mower is a manageable task with the right tools and approach. By systematically checking the battery, solenoid, and starter motor, you can pinpoint the issue and avoid unnecessary repairs.
