Mower Spindle Bearing Cross Reference Chart

Mower Spindle Bearing Cross Reference Chart(For All Brands)

Over time, spindle bearings can wear out due to heat, moisture, and debris, so knowing the correct bearing cross reference helps you find the perfect replacement quickly.

This comprehensive Mower Spindle Bearing Cross Reference Chart lists popular brands and part numbers, along with their compatible equivalents from other manufacturers.

Mower Spindle Bearing Cross Reference Chart

John Deere

OEM Part NumberBearing Type/SizeAftermarket EquivalentCompatible Models
JD9296, AM1183156203-2RS (17x40x12 mm)Stens 230-045, Peer 6203RSLT133, LX172, 100 Series, 102, 115, 125
AM372496205-2RS (25x52x15 mm)NTN 6205LLUC3, Timken 6205-2RSGT242, LX255, L120, L130, G110, X320
JD9239Z9504-RST (19.05×45.24×15 mm)Peer 204BBAR, Oregon 45-202X300, X500, 425, 445, 455
GY207856204-2RS (20x47x14 mm)Stens 230-100, Nachi 6204-2NSEL100, L108, L110, L118, D110, X130R
JD94496206-2RS (30x62x16 mm)Nachi 6206-2NSE, Stens 230-110X350, X570, Z425, Z445, 325

Husqvarna

OEM Part NumberBearing Type/SizeAftermarket EquivalentCompatible Models
5321104856203ZZ (17x40x12 mm)Oregon 45-100, Peer 6203ZZYTH20K46, LGT2654, RZ5424, Z246, Z4218
5321928706206-2RS (30x62x16 mm)Stens 230-110, Nachi 6206-2NSEYTH2348, Z254, GTH52XLS, RZ4623, TS354
539102626L44610 (tapered roller)Timken L44610, Stens 230-212TS348, TS354XD, Z248F, Z460, GT54CS
5321743586204-2RS (20x47x14 mm)Peer 6204-2RS, Oregon 45-102YTH22V46, RZ3016, LGT48DXL, Z242F
5391152796205ZZ (25x52x15 mm)NTN 6205ZZC3, Timken 6205ZZZ254F, TS342, YTH18542, GTH27V48LS

Related Mower Deck Spindle Bolts Torque Chart(For All Brands + Models)

Craftsman

OEM Part NumberBearing Type/SizeAftermarket EquivalentCompatible Models
121749X6203-2RS (17x40x12 mm)Oregon 45-100, NTN 6203LLBDYT4000, LT1000, GT5000, 917. series
5321928706206ZZ (30x62x16 mm)Peer 6206ZZ, Oregon 45-110LT2000, YT4000, 917.288 series, LTX1000
5321743446204-2RS (20x47x14 mm)Stens 230-100, Nachi 6204-2NSEYT3000, YT4500, 917.289 series, LT1500
5321307816205-2RS (25x52x15 mm)Timken 6205-2RS, Peer 6205RSGT6000, DLT2000, 917.275 series
5321385326203ZZ (17x40x12 mm)Oregon 45-104, NTN 6203ZZC3LT1000, 917.271 series, PYT9000

Toro

OEM Part NumberBearing Type/SizeAftermarket EquivalentCompatible Models
1105136204-2RS (20x47x14 mm)Stens 230-100, Nachi 6204-2NSETimeCutter SS, Recycler 22″, Titan ZT
1031196203ZZ (17x40x12 mm)Timken 6203ZZ, Oregon 45-104Wheel Horse, Titan ZX6000, TimeCutter MX
138-97706303-2RS (17x47x14 mm)NTN 6303LLB, Stens 230-150TimeCutter HD, ZX4800, MX5000, SS4225
103-24776205-2RS (25x52x15 mm)Peer 6205-2RS, Stens 230-110Titan ZX5450, TimeCutter ZS4200, MX6050
115-13996206-2RS (30x62x16 mm)Nachi 6206-2NSE, Oregon 45-110GrandStand, Z Master 2000, Titan MX5480

Related John Deere Bolt Torque Chart(Complete Guide)

Cub Cadet

OEM Part NumberBearing Type/SizeAftermarket EquivalentCompatible Models
941-04206203-2RS (17x40x12 mm)Oregon 45-100, Peer 6203RSXT1, RZT50, Z-Force S50, LT1045, XT2
941-04096204ZZ (20x47x14 mm)Nachi 6204ZZE, Stens 230-100RZT42, LTX1050, SLTX1054, CC30, ZT1 42
741-30666204-2RS (20x47x14 mm)Peer 6204-2RS, Timken 6204-2RSLTX1040, RZT54, ZT1 50, XT1 LT46
941-0656A6205-2RS (25x52x15 mm)Stens 230-110, Nachi 6205-2NSERZT-L 50, Z-Force L60, XT3 GSX
741-0919L44610 (tapered roller)Timken L44610, Oregon 45-212Z-Force Pro, RZT-S 46, Enforcer 48

MTD

OEM Part NumberBearing Type/SizeAftermarket EquivalentCompatible Models
741-041246203-2RS (17x40x12 mm)Oregon 45-100, Peer 6203RSTroy-Bilt Pony, Bronco, Yard-Man, TB30
741-04916205-2RS (25x52x15 mm)Nachi 6205-2NSE, Timken 6205-2RSYard Machines, Cub Cadet 54”, TB46, TB42
941-06556204-2RS (20x47x14 mm)Stens 230-100, Peer 6204-2RSTroy-Bilt Super Bronco, Mustang 46
741-07096206-2RS (30x62x16 mm)Oregon 45-110, Nachi 6206-2NSEYard-Man 42”, Troy-Bilt Horse, TB2246
741-0990A6203ZZ (17x40x12 mm)Timken 6203ZZ, Stens 230-045Bolens 38”, Troy-Bilt 42”, MTD 50”

Related Small Engine Torque Specs Chart(For All Makes + Models)

Bad Boy Mowers

OEM Part NumberBearing Type/SizeAftermarket EquivalentCompatible Models
037-6000-006204-2RS (20x47x14 mm)Oregon 45-102, NTN 6204LLUC3Maverick, ZT Elite, Outlaw XP, Pup
037-6020-006205-2RS (25x52x15 mm)Peer 6205-2RS, Nachi 6205-2NSEMZ Magnum, Rebel, Rogue, Renegade
010-7001-00L44610 (tapered roller)Timken L44610, Stens 230-212Lightning Z, AOS, Outlaw Extreme
037-6010-006206-2RS (30x62x16 mm)Oregon 45-110, Nachi 6206-2NSEZT60, Maverick HD, Revolt
037-2000-006203-2RS (17x40x12 mm)Stens 230-045, Peer 6203RSCompact Outlaw, Stand-On ZT, MZ42

Exmark

OEM Part NumberBearing Type/SizeAftermarket EquivalentCompatible Models
1-3035146203ZZ (17x40x12 mm)Stens 230-045, Peer 6203ZZLazer Z, Turf Tracer, Quest, Vantage
1-3033346205-2RS (25x52x15 mm)Oregon 45-110, NTN 6205LLBMetro, Navigator, Viking, Pioneer S
103-24776205-2RS (25x52x15 mm)Peer 6205-2RS, Stens 230-110Lazer Z XP, Radius, Pioneer, Quest E
1-543508L44610 (tapered roller)Timken L44610, Oregon 45-212Lazer Z HP, UltraCut, Staris
116-07206204-2RS (20x47x14 mm)Nachi 6204-2NSE, Stens 230-100Radius E, Quest S, Metro HP

Scag

OEM Part NumberBearing Type/SizeAftermarket EquivalentCompatible Models
4817086204-2RS (20x47x14 mm)Peer 6204-2RS, Stens 230-100Tiger Cat, Patriot, Freedom Z, Turf Tiger
48096-016205-2RS (25x52x15 mm)Nachi 6205-2NSE, Timken 6205RSCheetah, Liberty Z, V-Ride, STC48V
481657L44610 (tapered roller)Timken L44610, Oregon 45-212Turf Tiger, Wildcat, STT61V
4828386203-2RS (17x40x12 mm)Stens 230-045, Peer 6203RSV-Ride II, Cheetah II, Tiger Cat II
4810226206-2RS (30x62x16 mm)Oregon 45-110, Nachi 6206-2NSESTTII-61V, Patriot 52, Freedom Z 48

Related Lawn Mower Air Filter Size Chart(For All Brands + Models)

Ferris

OEM Part NumberBearing Type/SizeAftermarket EquivalentCompatible Models
50213476203ZZ (17x40x12 mm)Stens 230-045, Oregon 45-104IS600Z, IS700Z, ComfortControl, IS510Z
50213486205-2RS (25x52x15 mm)Peer 6205-2RS, Nachi 6205-2NSEISX800, IS2100Z, IS3200Z, ISX2200
5020884L44610 (tapered roller)Timken L44610, Stens 230-212IS1500Z, IS2000Z, IS3100Z, Evolution
51039106204-2RS (20x47x14 mm)Oregon 45-102, NTN 6204LLUC3ISX3300, IS700Z, IS2600Z
50234996206-2RS (30x62x16 mm)Nachi 6206-2NSE, Stens 230-110IS4000Z, IS4500Z, IS3200 Midnight

Grasshopper

OEM Part NumberBearing Type/SizeAftermarket EquivalentCompatible Models
6237806205-2RS (25x52x15 mm)Stens 230-110, Peer 6205-2RS120K, 225, 725DT, FrontMount 727, 928D
6440096204-2RS (20x47x14 mm)Oregon 45-102, Nachi 6204-2NSE124, 321D, 620T, FrontMount 618
6440106203-2RS (17x40x12 mm)Stens 230-045, Peer 6203RS720K, 725G2, 623T, 322D
120081L44610 (tapered roller)Timken L44610, Oregon 45-212729BT, 935G, FrontMount 900D
6440116206-2RS (30x62x16 mm)Nachi 6206-2NSE, Stens 230-110727K, 932, 721DT, MidMount 200

Related Lawn Mower Wheel Size Chart(All Brands + Models)

Snapper

OEM Part NumberBearing Type/SizeAftermarket EquivalentCompatible Models
17008456205-2RS (25x52x15 mm)Nachi 6205-2NSE, Oregon 45-110Pro ZTR, S200XT, 560Z, S800X, SPX275
70292766203-2RS (17x40x12 mm)Stens 230-045, Peer 6203RSNinja ZTR, 250Z, S50XT, LT150
70582376204-2RS (20x47x14 mm)Oregon 45-102, NTN 6204LLUC3S150XT, 400Z, SPX2246, LT200
70292756206-2RS (30x62x16 mm)Nachi 6206-2NSE, Stens 230-110500Z, S200X, SPX2548, FastCut
7026410L44610 (tapered roller)Timken L44610, Oregon 45-212Pro 7, ZT20500BV, S175X

Ariens

OEM Part NumberBearing Type/SizeAftermarket EquivalentCompatible Models
054162006203-2RS (17x40x12 mm)Stens 230-045, Peer 6203RSZoom 34, IKON X, Edge 52, Apex 48
215462356204-2RS (20x47x14 mm)Oregon 45-102, NTN 6204LLUC3Max Zoom, Apex 48, Gravely ZT XL, IKON XL
054070006205-2RS (25x52x15 mm)Peer 6205-2RS, Stens 230-110Zoom 42, Apex 60, IKON XD, Edge 34
054080006206-2RS (30x62x16 mm)Nachi 6206-2NSE, Oregon 45-110Apex 52, Zoom XL 48, IKON X 52
05406900L44610 (tapered roller)Timken L44610, Stens 230-212Pro-Zoom, Max Zoom 60, Apex 60

Related MTD Belt Size Chart(For ALL Models + Types)

Gravely

OEM Part NumberBearing Type/SizeAftermarket EquivalentCompatible Models
092537006205-2RS (25x52x15 mm)Peer 6205-2RS, Stens 230-110ZT HD, Pro-Turn Z, ZT X, Pro-QXT
09246900L44610 (tapered roller)Timken L44610, Oregon 45-212Pro-Stance, Pro-Turn 200, ZT HD 60
092538006203-2RS (17x40x12 mm)Stens 230-045, Peer 6203RSZT XL, Pro-Walk, ZT 34, Pro-Turn 48
092539006204-2RS (20x47x14 mm)Oregon 45-102, NTN 6204LLUC3ZT HD 44, Pro-Turn ZX, ZT XL 42
092540006206-2RS (30x62x16 mm)Nachi 6206-2NSE, Stens 230-110Pro-Turn 260, ZT HD 52, Pro-QXT 48

How to Identify Your Mower Spindle Bearing

1. Check the OEM Number:

Most bearings have a stamped number (e.g., 6203-2RS). You can also refer to your mower’s manual or parts diagram.

2. Measure Bearing Dimensions:

Use a caliper to measure inner diameter (ID), outer diameter (OD), and width. Common mower bearing sizes include:

  • 6203: 17x40x12 mm
  • 6204: 20x47x14 mm
  • 6205: 25x52x15 mm
  • 6206: 30x62x16 mm

4. Choose the Right Seal Type:

  • 2RS → Double rubber sealed (best for dusty/muddy conditions)
  • ZZ → Double metal shielded (good for high-speed applications)

Related Mower Productivity Chart(For All Brands + Models)

Signs of Worn Spindle Bearings

  • Unusual grinding or squealing noise while mowing
  • Blades wobble or vibrate excessively
  • The mower deck doesn’t cut evenly
  • Resistance when manually rotating the spindle pulley

If you notice any of these symptoms, inspect and replace your spindle bearings before they cause damage to the spindle housing or mower blades.

Replacing Mower Spindle Bearings

  1. Remove the mower deck and detach the spindle assembly.
  2. Use a bearing puller or press to remove the old bearings.
  3. Clean the housing and check for damage or corrosion.
  4. Press in the new bearings gently using a bearing driver or socket.
  5. Reassemble the spindle, ensuring seals are intact and pulleys rotate freely.

Recommended High-Quality Replacement Bearing Brands

  • Peer Bearings – OEM-quality replacements used by John Deere and Scag.
  • NTN – Long lifespan with precision sealing technology.
  • Nachi – Known for heat resistance and durability in tough mowing conditions.
  • Timken – Premium-grade steel bearings with reliable load capacity.
  • Oregon/Stens – Affordable aftermarket solutions that fit most mower models.

FAQs

What size are most mower spindle bearings?

Most common sizes are 6203-2RS (17x40x12 mm) and 6204-2RS (20x47x14 mm), though some larger decks use 6205 or 6206 bearings.

Can you grease sealed spindle bearings?

No, 2RS or ZZ bearings are sealed and do not require greasing. However, ensure your spindle housing’s grease fittings are serviced if your model allows.

How long do mower spindle bearings last?

With proper care and lubrication, they typically last 3–5 years, depending on mowing frequency and conditions.

Can I replace spindle bearings without replacing the whole spindle?

Yes. If the housing and spindle shaft are in good shape, you can just replace the bearings to save costs.

Are all 6203 bearings the same?

While dimensions are identical, quality and seal type vary by brand. Choose a reputable manufacturer for longer performance.
