The deck belt is a crucial component that helps drive the mower blades. If the belt is too loose or tight, it can cause performance issues, unusual noises, and even damage to the mower’s drive system. That’s why knowing your Snapper ZT Rider 24HP 50 in deck belt size is essential.
Snapper ZT Rider 24HP 50 in Deck Belt Size Chart
Model Number | Engine HP | Deck Size | Belt Type | Belt Length | Belt Width | OEM Part Number |
---|---|---|---|---|---|---|
Snapper ZT2450 | 24 HP | 50 in | Deck Drive | 151.25 in | 1/2 in | 5023256 |
Snapper ZT2500 | 25 HP | 50 in | Deck Drive | 151.25 in | 1/2 in | 5023256 |
Snapper ZT2550 | 25 HP | 50 in | Deck Drive | 151.25 in | 1/2 in | 5023256 |
Snapper ZT2650 | 26 HP | 50 in | Deck Drive | 151.25 in | 1/2 in | 5023256 |
Snapper ZT25480 | 24 HP | 50 in | Deck Drive | 151.25 in | 1/2 in | 5023256 |
Snapper ZT26520 | 26 HP | 52 in | Deck Drive | 148.9 in | 1/2 in | 1732951SM |
Snapper 355Z | 24 HP | 50 in | Deck Drive | 151.25 in | 1/2 in | 5023256 |
Snapper 360Z | 25 HP | 50 in | Deck Drive | 151.25 in | 1/2 in | 5023256 |
Snapper 400Z | 24 HP | 50 in | Deck Drive | 151.25 in | 1/2 in | 5023256 |
Related Mowing Time By Deck Size Calculator
How to Measure Your Mower Belt Accurately
If you’ve lost your manual or can’t find your model number, you can still measure your belt manually:
- Remove the belt and lay it flat.
- Use a flexible tape measure.
- Measure outer circumference.
- Confirm belt width using a caliper.
Pro Tip: Always round up to the nearest inch when measuring length.
Symptoms of a Worn-Out Belt
Watch out for these signs:
- Squealing noises while mowing
- Inconsistent blade speed
- Slipping or stalling blades
- Cracks or frays along the belt
Replacing your mower’s belt at the first sign of wear saves you time and money in the long run.
Related Gravely Belt Size Chart(For All Models)
How to Replace the Deck Belt on a Snapper ZT Rider
Tools Needed
- Socket wrench set
- Belt removal tool
- Safety gloves
- Jack (to lift mower deck)
Step-by-Step Instructions
- Turn off mower and remove spark plug.
- Engage parking brake and lift mower deck.
- Remove the belt guards and loosen pulleys.
- Take off the old belt.
- Route new belt as per diagram (check under seat or manual).
- Tighten everything and test run.
Related Toro Belt Size Chart(Updated For All Models)
Tips for Belt Maintenance and Longevity
- Clean deck regularly: Grass clippings cause friction.
- Check tension: Monthly checks prevent looseness.
- Avoid overloading blades: Mowing wet or thick grass stresses the belt.
- Store indoors: Protects rubber from weather damage.
FAQs
What is the belt size for Snapper ZT2450?
The belt is approximately 146.6 inches in length and 1/2 inch wide, with OEM part number 1732201SM.
Related John Deere Belt Size Chart(For All JD Models)
Can I use a non-OEM belt for my Snapper ZT Rider?
Yes, but it’s not recommended. Non-OEM belts may not fit properly and can void the warranty.
How often should I replace my mower belt?
Typically every 2-3 years, or sooner if signs of wear appear.
Is the same belt used for transmission and deck?
No. The transmission and deck use different belts, always refer to the manual for specifics.
Can I change the belt without professional help?
Yes, if you have basic tools and follow proper safety guidelines, it’s a DIY-friendly task.
What happens if I install the wrong belt?
You’ll face slipping, blade inefficiency, and potential damage to your mower’s system.
