The Toro Flex 800 series is a robust and flexible irrigation system, specifically designed for large-scale turf applications like golf courses, sports fields, and parks. What sets it apart is the wide variety of nozzles available, each engineered to deliver precision watering with maximum efficiency.
This guide covers the essential nozzle data and provides insights to help you optimize your irrigation layout using the official Toro Flex 800 nozzle chart.
Toro Flex 800 Nozzle Chart
Nozzle # | Color | Pressure (psi) | Radius (ft) | Flow (GPM) | Precip Rate (in/hr, Square) | Precip Rate (in/hr, Triangular) | Trajectory |
---|---|---|---|---|---|---|---|
31 | Red | 50 | 52 | 12.9 | 0.46 | 0.53 | 25° / 15° |
31 | Red | 65 | 54 | 14.8 | 0.49 | 0.57 | 25° / 15° |
31 | Red | 80 | 56 | 16.3 | 0.50 | 0.58 | 25° / 15° |
32 | Red | 50 | 55 | 15.4 | 0.49 | 0.57 | 25° / 15° |
32 | Red | 65 | 57 | 17.7 | 0.52 | 0.60 | 25° / 15° |
32 | Red | 80 | 59 | 19.5 | 0.54 | 0.62 | 25° / 15° |
33 | Black | 50 | 58 | 18.2 | 0.52 | 0.60 | 25° / 15° |
33 | Black | 65 | 60 | 20.8 | 0.55 | 0.64 | 25° / 15° |
33 | Black | 80 | 62 | 22.9 | 0.57 | 0.66 | 25° / 15° |
34 | Black | 50 | 62 | 22.0 | 0.55 | 0.64 | 25° / 15° |
34 | Black | 65 | 65 | 25.2 | 0.57 | 0.66 | 25° / 15° |
34 | Black | 80 | 67 | 27.7 | 0.59 | 0.68 | 25° / 15° |
51 | Black | 50 | 62 | 18.8 | 0.47 | 0.54 | 25° / 15° |
51 | Black | 65 | 65 | 21.5 | 0.49 | 0.57 | 25° / 15° |
51 | Black | 80 | 67 | 23.7 | 0.51 | 0.59 | 25° / 15° |
52 | Black | 50 | 65 | 22.2 | 0.51 | 0.59 | 25° / 15° |
52 | Black | 65 | 68 | 25.5 | 0.53 | 0.61 | 25° / 15° |
52 | Black | 80 | 71 | 28.0 | 0.53 | 0.61 | 25° / 15° |
53 | Beige | 50 | 68 | 26.2 | 0.55 | 0.63 | 25° / 15° |
53 | Beige | 65 | 72 | 30.1 | 0.56 | 0.65 | 25° / 15° |
53 | Beige | 80 | 75 | 33.0 | 0.57 | 0.66 | 25° / 15° |
54 | Beige | 50 | 72 | 30.8 | 0.57 | 0.66 | 25° / 15° |
54 | Beige | 65 | 76 | 35.3 | 0.59 | 0.68 | 25° / 15° |
54 | Beige | 80 | 80 | 38.8 | 0.58 | 0.67 | 25° / 15° |
55 | Beige | 65 | 78 | 39.5 | 0.63 | 0.73 | 25° / 15° |
55 | Beige | 80 | 82 | 43.5 | 0.62 | 0.72 | 25° / 15° |
55 | Beige | 100 | 85 | 48.4 | 0.65 | 0.75 | 25° / 15° |
Related Toro Snowblower Spark Plug Chart(For All Models)
Notes:
- Nozzle Range: Nozzles 31–34 (for FLX34 models) and 51–55 (for FLX54/55 models), with radii from 52 to 85 feet.
- Color Coding: Red (lowest flow, nozzles 31–32), Black (medium flow, nozzles 33–34, 51–52), Beige (high flow, nozzles 53–55).
- Trajectory: Dual trajectory nozzles (25° standard or 15° low angle for windy conditions).
- Precipitation Rates: Calculated for square and triangular spacing, assuming optimal distribution.
Understanding PSI and GPM in Irrigation
Before jumping into the chart, let’s break down two key terms:
- PSI (Pounds per Square Inch): Measures water pressure entering the nozzle.
- GPM (Gallons per Minute): Measures the amount of water flowing through the nozzle.
For optimal performance, you must match the PSI and GPM requirements of your sprinkler zone with the specifications in the nozzle chart.
Related Toro Belt Size Chart(Updated For All Models)
Nozzle Color Coding Explained
Toro uses a color-coded system to help users quickly identify nozzle types and their flow rates. For instance:
- Red = Lowest flow
- Black = Medium flow
- Beige = High flow
Choosing the Right Nozzle for Your Turf
When selecting a nozzle, consider:
- Turf size: Larger areas benefit from higher GPM and longer radius.
- Water pressure: Match PSI to your existing system.
- Slope & terrain: Use lower trajectory nozzles (15°) for windy or sloped areas.
- Overlap: Ensure 100% head-to-head coverage
Related Toro Zero Turn Front Tire Pressure Chart(For All Models)
Comparison with Other Toro Nozzle Series
Feature | Flex 800 Series | Flex 700 Series | Flex 600 Series |
---|---|---|---|
Coverage Area | Largest | Medium | Small |
Pressure Regulation | Yes | Yes | Limited |
Nozzle Variety | Extensive | Moderate | Few |
Durability | High | High | Moderate |
FAQs
How do you adjust Toro sprinkler nozzles?
To adjust a Toro sprinkler nozzle, follow these steps:
- Pop up the sprinkler by turning on the water or pulling it up manually.
- Use a flathead screwdriver or Toro’s adjustment tool.
- To adjust the spray distance:
- Turn the radius reduction screw clockwise to decrease the distance.
- Turn it counterclockwise to increase it.
- To adjust the spray pattern or arc:
- Insert the tool into the arc adjustment slot.
- Turn clockwise to increase the arc (up to 360°).
- Turn counterclockwise to decrease the arc (down to 40°).
Tip: Always make adjustments while the system is running so you can immediately see the changes.
Related Toro Oil Filter Cross Reference Chart(All Models)
What is the color code for Toro sprinkler nozzles?
Toro sprinkler nozzles use a color-coded system to indicate their flow rate (GPM) and model type. Here’s a basic color guide:
Color | Typical Flow Range (GPM) | Application |
---|---|---|
Red | 6.8 | Low flow |
Blue | 7.9 | Low-medium flow |
Green | 9.2 | Medium flow |
Brown | 10.5 | Medium-high |
Gray | 11.8 | High flow |
Black | 13.1 | Higher flow |
Beige | 14.4 | Maximum flow |
Note: Color coding may differ between product lines, so always consult the Toro nozzle chart specific to your series.
How do you adjust Toro Super 800 sprinkler heads?
To adjust a Toro Super 800 sprinkler head, do the following:
- Adjust Arc (Spray Angle):
- Use the Toro adjustment key or screwdriver.
- Insert it into the arc adjustment slot on top.
- Turn clockwise to increase arc, counterclockwise to decrease.
- Adjust Radius (Spray Distance):
- Use the radius screw near the nozzle.
- Turn clockwise to shorten spray.
- Turn counterclockwise to lengthen spray.
- Change Nozzles (if needed):
- Pull the riser stem up and hold it.
- Unscrew the current nozzle and replace it with a new one from the Toro nozzle kit.
- Ensure Proper Alignment:
- Turn the head manually to align the spray with the target area.
How to read sprinkler nozzles?
To read a sprinkler nozzle, look at the following markings:
- Nozzle number (e.g., 30, 45, 60): Indicates flow rate range.
- Manufacturer code: Usually stamped or molded onto the nozzle.
- Color: Corresponds to the flow category.
- Spray pattern (e.g., 90°, 180°, 360°): For fixed spray heads.
For Toro nozzles, the number and color together help you determine:
- GPM (gallons per minute)
- Spray distance (radius)
- Pressure requirements (PSI)
How do you read a nozzle chart?
A nozzle chart shows specifications like:
Nozzle # | PSI | GPM | Radius (Feet) | Trajectory (°) |
---|---|---|---|---|
30 | 65 | 6.8 | 36 | 25 |
Here’s how to read it:
- Nozzle #: Identifier (usually matches the number on the nozzle).
- PSI: The pressure required for optimal performance.
- GPM: Flow rate — important for water budgeting.
- Radius: Distance the water sprays from the sprinkler.
- Trajectory: Angle of spray — affects how the water lands (useful in windy areas).
What are the specifications of a nozzle?
Sprinkler nozzle specifications typically include:
- Flow rate (GPM): How much water the nozzle delivers per minute.
- Operating pressure (PSI): Ideal water pressure range.
- Spray radius (feet): Distance water is distributed.
- Spray angle or arc (°): Coverage area (e.g., 90°, 180°, 360°).
- Trajectory angle (°): Height and direction of water arc.
- Material: Usually plastic or brass.
- Thread type: Determines compatibility with sprinkler bodies.
- Color code: Indicates flow rate category.
These specs help you design a balanced, efficient irrigation system.
