This guide provides a comprehensive John Deere skid steer size chart, allowing you to compare models side by side. Models are grouped by frame size: Small-Frame, Mid-Frame, and Large-Frame. Each size category offers different levels of power, lift height, maneuverability, and fuel efficiency.
John Deere Skid Steer Size Chart
| Model | Rated Operating Capacity (lbs) | Operating Weight (lbs) | Engine HP | Lift Type | Width (in) | Height (in) | Tipping Load (lbs) |
|---|---|---|---|---|---|---|---|
| 312GR | 1,550 | 5,995 | 48 | Radial | 60.0 | 76.5 | 3,100 |
| 314G | 1,700 | 6,100 | 52 | Radial | 61.0 | 77.0 | 3,400 |
| 316GR | 1,750 | 6,350 | 61 | Radial | 60.0 | 77.0 | 3,500 |
| 318G | 1,900 | 6,175 | 65 | Radial | 61.0 | 77.5 | 3,800 |
| 320G | 2,190 | 7,150 | 69 | Radial | 67.0 | 80.0 | 4,400 |
| 324G | 2,690 | 7,600 | 74 | Vertical | 69.0 | 80.0 | 5,380 |
| 326G | 2,600 | 8,300 | 74 | Vertical | 70.0 | 82.0 | 5,200 |
| 328G | 2,800 | 9,500 | 91 | Vertical | 72.0 | 82.5 | 5,600 |
| 332G | 3,600 | 10,000 | 100 | Vertical | 76.0 | 83.0 | 7,200 |
| 318E | 1,800 | 6,150 | 61 | Radial | 59.0 | 76.0 | 3,600 |
| 320E | 2,000 | 7,200 | 66 | Radial | 66.0 | 80.0 | 4,000 |
| 326E | 2,600 | 8,500 | 74 | Radial | 70.0 | 80.5 | 5,200 |
| 328E | 2,800 | 9,200 | 91 | Radial | 71.0 | 81.0 | 5,600 |
| 329E | 2,900 | 9,600 | 91 | Vertical | 72.0 | 81.0 | 5,800 |
| 332E | 3,200 | 9,800 | 100 | Vertical | 74.0 | 81.5 | 6,400 |
| 240 (Legacy) | 1,500 | 6,000 | 49 | Radial | 60.0 | 75.0 | 3,000 |
| 250 (Legacy) | 1,750 | 6,800 | 56 | Radial | 66.0 | 78.0 | 3,500 |
| 260 (Legacy) | 2,000 | 7,700 | 69 | Radial | 69.0 | 80.0 | 4,000 |
| 270 (Legacy) | 2,500 | 8,200 | 79 | Vertical | 70.0 | 81.0 | 5,000 |
| 280 (Legacy) | 2,900 | 9,000 | 90 | Vertical | 72.0 | 82.0 | 5,800 |
| 313 | 1,300 | 5,100 | 45 | Radial | 58.0 | 75.0 | 2,600 |
| 315 | 1,500 | 5,500 | 48 | Radial | 59.0 | 76.0 | 3,000 |
| 317G | 2,125 | 6,700 | 65 | Vertical | 65.0 | 80.0 | 4,250 |
| 315C | 1,750 | 6,150 | 61 | Radial | 60.0 | 76.5 | 3,500 |
| 270 Skid Loader (Older Tour) | 2,450 | 8,100 | 79 | Vertical | 70.5 | 80.2 | 4,900 |
| 8875 (New Holland Era) | 2,200 | 7,800 | 84 | Vertical | 68.0 | 79.0 | 4,400 |
Related John Deere Skid Steer Troubleshooting(5 Quick Ways To Fix)
How to Choose the Right Size John Deere Skid Steer
1. Job Environment and Space
- For tight access or indoor barn cleaning, choose a small-frame model like the 312GR or 318G.
- For open-field or construction sites, mid and large-frame models perform better.
2. Lift Capacity Requirements
Consider the heaviest load you will frequently lift.
- Light landscaping: 1,550–1,900 lb range (312GR–318G).
- General construction: 2,100–2,900 lb range (320G–329E).
- Heavy industrial lifting: 3,000+ lb (332E–332G).
3. Lift Path
- Radial Lift is ideal for digging, grading, and pushing material.
- Vertical Lift is better for loading trucks and stacking pallets because it maintains a more level lift path.
4. Hydraulic Flow
If you plan to use hydraulic attachments (grinders, trenchers, brush cutters):
- Choose models with high-flow hydraulics like the 328G or 332G.
Related John Deere Bolt Torque Chart(Complete Guide)
Common Attachments That Fit John Deere Skid Steers
| Attachment | Best Use Case |
|---|---|
| Bucket | Moving soil, gravel, snow, sand |
| Pallet Forks | Material loading and warehouse handling |
| Auger | Fence posts and planting |
| Grapple | Scrap, logs, brush handling |
| Trencher | Utility and irrigation line installation |
| Brush Cutter | Land clearing and vegetation management |
FAQs
What are the sizes of John Deere skid steers?
John Deere skid steers come in three main size categories based on operating capacity and frame dimensions:
- Small-Frame: 1,550–1,900 lb lift capacity (e.g., 312GR, 318G)
- Mid-Frame: 2,000–2,800 lb lift capacity (e.g., 320G, 326G)
- Large-Frame: 3,000+ lb lift capacity (e.g., 332G, 333G compact track loader equivalent)
Small models are best for tight spaces and light tasks, while larger models handle heavy lifting and industrial work.
Related John Deere Combine Settings Chart(Ultimate Guide)
What is a standard size skid steer?
A “standard” or average skid steer generally falls in the mid-frame range, offering:
- 2,000–2,600 lbs operating capacity
- 66–75 HP engine power
- 66–75 inches wide
This size works for most general construction and landscaping needs.
What are the specs on a John Deere 250 skid steer?
The 250 was popular because it offered reliable power in a compact frame.
| Specification | Value |
|---|---|
| Rated Operating Capacity | ~1,750 lbs |
| Operating Weight | ~6,800 lbs |
| Engine Power | 56 HP |
| Lift Type | Radial Lift |
| Width | ~66 inches |
| Height | ~78 inches |
| Tipping Load | ~3,500 lbs |
How wide is a John Deere 325G skid steer?
The John Deere 325G is technically a compact track loader (CTL), not a wheeled skid steer, but it is commonly compared to one.
- Width with standard tracks: ~70 inches
- Width with wide tracks: ~74 inches
Its size is similar to a mid-to-large skid steer.
What is a full size skid steer?
A full-size skid steer typically refers to large-frame models, with:
- 3,000+ lbs rated lift capacity
- 90–100+ HP engines
- Width around 72–78 inches
These machines are used for heavy-duty construction, demolition, and industrial lifting tasks.
Examples include 332G and older 332E models.
Related Mower Spindle Bearing Cross Reference Chart(For All Brands)
How wide is a 333G John Deere skid steer?
The John Deere 333G is also a compact track loader, but commonly compared in size to a large skid steer.
- Width: ~78 inches (standard tracks)
It is considered one of the largest and most powerful compact loaders in the John Deere lineup.
Final Thoughts
Choosing the right John Deere skid steer depends on your work requirements, space limitations, and material handling needs. Small-frame models are great for maneuverability and efficiency in tight work areas, while large-frame models offer high horsepower and lifting performance for demanding tasks.
Use the size chart above to compare specifications and select the skid steer that matches your job needs and operating style.
