In this post guide, we’ll explore the reasons behind oil in the exhaust, how to diagnose the issue, and steps to fix it, ensuring your lawn mower runs smoothly again.
Oil Coming Out of Lawn Mower Exhaust
1. Overfilled Oil Reservoir
One of the most frequent culprits is overfilling the oil reservoir. When too much oil is added, excess oil can make its way into the combustion chamber. This happens because the crankcase pressure pushes oil past the piston rings or into the valve guides, leading to oil being burned or expelled through the exhaust.
2. Tipping the Mower Incorrectly
Lawn mowers are designed to operate in an upright position. Tipping the mower on its side or upside down, especially during maintenance or cleaning, can cause oil to flow from the crankcase into the cylinder or exhaust system. This is particularly common with mowers that lack proper oil sealing mechanisms.
3. Worn Piston Rings or Cylinder Walls
In older mowers or those with heavy use, worn piston rings or scored cylinder walls can allow oil to seep into the combustion chamber. This oil then burns during operation, producing blue or white smoke and potentially exiting through the exhaust.
Related John Deere Exhaust Filter Indicator(Avoid Engine Damage)
4. Faulty Breather Valve
The breather valve, part of the crankcase ventilation system, helps regulate pressure in the crankcase. If the breather valve is clogged or malfunctioning, excessive pressure can force oil into the combustion chamber or exhaust, leading to oil leakage.
5. Damaged or Worn Gaskets
Gaskets, such as those around the cylinder head or valve cover, seal critical engine components. If these gaskets are damaged or worn, oil can leak into areas where it’s not meant to go, including the exhaust system.
6. Incorrect Oil Type
Using the wrong type or viscosity of oil can cause problems. Oil that’s too thin may not provide adequate lubrication, while oil that’s too thick can create excessive pressure, pushing oil into the combustion chamber.
Related Why Lawn Mower Backfires(5 Reasons + Solutions)
Diagnosing the Issue
To pinpoint the cause, start with a systematic inspection:
- Check Oil Levels: Use the dipstick to verify if the oil level is above the recommended mark. Overfilling is a common issue and easy to correct.
- Inspect for Smoke: Run the mower and observe the exhaust. Blue or white smoke often indicates oil burning in the combustion chamber.
- Review Maintenance Habits: Reflect on whether the mower was recently tipped or mishandled, which could have caused oil to flow into the wrong areas.
- Examine the Air Filter: A clogged or oil-soaked air filter can indicate crankcase pressure issues or oil entering the intake.
- Listen for Unusual Sounds: Knocking or sputtering may suggest internal engine problems, such as worn piston rings or damaged components.
Related Why Is My Husqvarna Lawn Mower Surging(6 Causes + Solutions)
Solutions to Fix Oil in the Exhaust
1. Correct Oil Levels
If the oil reservoir is overfilled, drain the excess oil. Refer to your mower’s manual for the correct oil capacity, and use a dipstick to ensure the level is within the recommended range.
2. Clean the Exhaust System
If oil has entered the exhaust, remove the muffler (if possible) and clean it thoroughly to prevent clogs or further smoking. Check for oil residue in the exhaust pipe and clean it with a degreaser.
Related Kohler Engine Spewing Liquid out of Breather(Solved)
3. Address Tipping Issues
If the mower was tipped incorrectly, run it for a few minutes in the upright position to allow oil to settle back into the crankcase. Remove and clean the spark plug if it’s fouled with oil, and replace the air filter if necessary.
4. Replace Worn Components
For worn piston rings or cylinder walls, a professional repair or engine rebuild may be required. This is more complex and may not be cost-effective for older mowers, so consider the mower’s age and value before proceeding.
5. Fix the Breather Valve
Inspect the breather valve for clogs or damage. Clean or replace it as needed to restore proper crankcase ventilation.
Related Briggs and Stratton Leaking Oil From Bottom(5 Causes and Solutions)
6. Replace Gaskets
If gaskets are the issue, replace them with parts specified by the manufacturer. This may require disassembling parts of the engine, so consult the manual or seek professional help if you’re unsure.
7. Use the Correct Oil
Ensure you’re using the oil type and viscosity recommended by the manufacturer, typically SAE 30 or 10W-30 for most small engines. Check the manual for specifics.
Related How to Remove PTO Clutch Bolt(In 5 Quick Steps)
Preventing Future Issues
To avoid oil in the exhaust in the future:
- Always check oil levels before adding more.
- Tip the mower only as recommended by the manufacturer, usually with the spark plug facing upward.
- Perform regular maintenance, including oil changes, air filter cleaning, and spark plug checks.
- Store the mower on a level surface to prevent oil from shifting.
Final words
Oil coming out of a lawn mower’s exhaust is a sign that something’s amiss, but it’s often fixable with the right approach. By identifying the cause, whether it’s overfilled oil, improper handling, or worn components, you can take targeted steps to resolve the issue.
Regular maintenance and proper operation are essential for keeping your mower in top condition. With these tips, you’ll be back to mowing your lawn efficiently in no time.
